如今业务系统对于缓存Redis的使用依赖似乎是必不可少的，我们可以在各种各样的建高s集系统中看到Redis的身影。考虑到系统运行的可用稳定性，Redis的使用应用和MySQL数据库一样需要做到高可用部署。
一、建高s集Redis 的可用多种高可用方案
常见的Redis的高可用方案有以下几种：
Redis Replication（主从复制）：Redis的主从复制可以实现数据的备份和读写分离。通过配置主节点和从节点，使用主节点将数据异步复制到从节点上。建高s集当主节点发生故障时，可用一个从节点可以被提升为新的使用主节点，实现故障转移。建高s集主从复制适用于对读操作较多、可用对可用性要求较高的使用场景。Redis Sentinel（哨兵模式）：哨兵模式是建高s集Redis官方推荐的实现高可用的方案之一。通过运行一个或多个Sentinel进程，可用监控Redis主节点的状态。
服务器托管当主节点故障时，Sentinel会自动进行故障转移，将其中一个从节点提升为新的主节点。哨兵还可以监控从节点并进行故障恢复。
哨兵模式适用于对高可用性要求不是特别高的场景。Redis Cluster（集群模式）：Redis Cluster是Redis官方提供的高可用和分布式解决方案。通过将多个Redis实例组成一个集群，Redis Cluster提供了自动的数据分片和高可用性。数据被分配到不同的节点上，并使用Gossip协议进行节点之间的通信。当有节点发生故障时，Redis Cluster可以自动将数据迁移到其他正常的节点上。Redis Cluster适用于对可用性和扩展性要求较高的场景。集群模式只能存储在db0。第三方中间件/解决方案：除了Redis官方提供的高可用方案，还有一些第三方中间件或解决方案可以用于实现Redis的高可用，如Codis、Twemproxy等。这些中间件提供了更多的功能和扩展性，如代理、
源码库负载均衡、故障恢复等。
在选择高可用方案时，需要考虑系统的可用性需求、数据一致性要求、网络拓扑等因素。同时，也要注意进行适当的测试和监控，确保Redis集群的稳定性和高可用性。
二、使用Docker Compose安装Redis并配置哨兵模式（Redis Sentinel）
1、环境准备
集群的架构一般服务器为奇数台，所以，如果是采用集群模式，那么至少准备3台Linux服务器，受生产环境所限，我们只有两台Linux服务器，但是我们可以使用Docker搭建多个Redis服务(Redis主服务1、Redis从服务2、Redis从服务3)：
192.168.0.210 (Redis主服务1、Redis从服务2)。192.168.0.195 (Redis从服务3)。
2、准备Redis文件存放目录
准备Redis存储目录，在两台主从服务器上分别执行一下命令。
在192.168.0.210服务器上执行Redis主服务1所需目录及权限命令。 复制mkdir -p /opt/container/redis/master/data /opt/container/redis/master/conf /opt/container/redis/master/logs /opt/container/redis/sentinel/data /opt/container/redis/sentinel/conf /opt/container/redis/sentinel/logs chmod -R 777 /opt/container/redis/master/data /opt/container/redis/master/conf /opt/container/redis/master/logs /opt/container/redis/sentinel/data /opt/container/redis/sentinel/conf /opt/container/redis/sentinel/logs1.2.3.
在192.168.0.210服务器上执行Redis从服务2所需目录及权限命令。香港云服务器
复制mkdir -p /opt/container/redis/slave1/data /opt/container/redis/slave1/conf /opt/container/redis/slave1/logs /opt/container/redis/sentinel1/data /opt/container/redis/sentinel1/conf /opt/container/redis/sentinel1/logs chmod -R 777 /opt/container/redis/slave1/data /opt/container/redis/slave1/conf /opt/container/redis/slave1/logs /opt/container/redis/sentinel1/data /opt/container/redis/sentinel1/conf /opt/container/redis/sentinel1/logs1.2.3.
在192.168.0.195服务器上执行Redis从服务3所需目录及权限命令。
复制mkdir -p /opt/container/redis/slave2/data /opt/container/redis/slave2/conf /opt/container/redis/slave2/logs /opt/container/redis/sentinel2/data /opt/container/redis/sentinel2/conf /opt/container/redis/sentinel2/logs chmod -R 777 /opt/container/redis/slave2/data /opt/container/redis/slave2/conf /opt/container/redis/slave2/logs /opt/container/redis/sentinel2/data /opt/container/redis/sentinel2/conf /opt/container/redis/sentinel2/logs1.2.3.
/opt/container/redis/ ** /data 用于存放Redis数据文件。
/opt/container/redis/ ** /conf 用于存放Redis配置文件。
/opt/container/redis/ ** /logs 用于存放Redis日志文件。
/opt/container/sentinel/ ** /data 用于存放Redis哨兵数据文件。
/opt/container/sentinel/ ** /conf 用于存放Redis哨兵配置文件。
/opt/container/sentinel/ ** /logs 用于存放Redis哨兵日志文件。
3、Redis服务器docker-compose.yml文件
192.168.0.210服务器上部署两个Redis服务(Redis主服务1、Redis从服务2)的docker-compose-redis.yml文件 复制version: 3 services: ##redis主配置 redisMaster: image: redis:latest restart: always container_name: redis-master command: redis-server /usr/local/etc/redis/redis.conf ##将26381映射到26381上 ports: - "26381:26381" volumes: ##数据目录，要确保先创建好 - /opt/container/redis/master/data:/data - /opt/container/redis/master/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/master/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" ##redis从配置 redisSlave1: image: redis:latest restart: always container_name: redis-slave-1 command: redis-server /usr/local/etc/redis/redis.conf ##将26382映射到26382上 ports: - "26382:26382" volumes: ##数据目录，要确保先创建好 - /opt/container/redis/slave1/data:/data - /opt/container/redis/slave1/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/slave1/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" sentinel: image: redis:latest restart: always container_name: redis-sentinel ports: - 36381:36381 command: redis-sentinel /opt/redis/sentinel/sentinel.conf volumes: - /opt/container/redis/sentinel/data:/data - /opt/container/redis/sentinel/conf/sentinel.conf:/opt/redis/sentinel/sentinel.conf - /opt/container/redis/sentinel/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" sentinel1: image: redis:latest restart: always container_name: redis-sentinel-1 ports: - 36382:36382 command: redis-sentinel /opt/redis/sentinel/sentinel1.conf volumes: - /opt/container/redis/sentinel1/data:/data - /opt/container/redis/sentinel1/conf/sentinel1.conf:/opt/redis/sentinel/sentinel1.conf - /opt/container/redis/sentinel1/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone"1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.38.39.40.41.42.43.44.45.46.47.48.49.50.51.52.53.54.55.56.57.58.59.60. 192.168.0.195服务器上部署Redis服务(Redis从服务3)的docker-compose-redis-slave.yml文件。 复制version: 3 services: ##redis从2配置 redisSlave2: image: redis:latest restart: always container_name: redis-slave-2 command: redis-server /usr/local/etc/redis/redis.conf ##将26383映射到26383上 ports: - "26383:26383" volumes: ##数据目录，要确保先创建好 - /opt/container/redis/slave2/data:/data - /opt/container/redis/slave2/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/slave2/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" sentinel2: image: redis:latest restart: always container_name: redis-sentinel-2 ports: - 36383:36383 command: redis-sentinel /opt/redis/sentinel/sentinel2.conf volumes: - /opt/container/redis/sentinel2/data:/data - /opt/container/redis/sentinel2/conf/sentinel2.conf:/opt/redis/sentinel/sentinel2.conf - /opt/container/redis/sentinel2/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone"1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.
4、准备Redis服务的配置文件
192.168.0.210主Redis配置文件，配置端口26381，Redis密码，并将配置文件redis.conf上传至/opt/container/redis/master/conf目录。 复制appendonly yes port 26381 appendfilename appendonly.aof appendfsync everysec auto-aof-rewrite-min-size 10M auto-aof-rewrite-percentage 100 requirepass "设置密码" masterauth "设置密码" replica-read-only no1.2.3.4.5.6.7.8.9.10. 192.168.0.210从Redis配置文件，配置端口26382，密码，并将配置文件redis.conf上传至/opt/container/redis/slave1/conf目录。 复制appendonly yes port 26382 appendfilename appendonly.aof appendfsync everysec auto-aof-rewrite-min-size 10M auto-aof-rewrite-percentage 100 requirepass "设置密码" replicaof 192.168.0.210 26381 masterauth "设置密码" replica-read-only no1.2.3.4.5.6.7.8.9.10.11. 192.168.0.195从Redis配置文件，配置端口26383，密码，并将配置文件redis.conf上传至/opt/container/redis/slave2/conf目录。 复制appendonly yes port 26383 appendfilename appendonly.aof appendfsync everysec auto-aof-rewrite-min-size 10M auto-aof-rewrite-percentage 100 requirepass "设置密码" replicaof 192.168.0.210 26381 masterauth "设置密码" replica-read-only no1.2.3.4.5.6.7.8.9.10.11.
5、准备Redis哨兵的配置文件，每个Redis服务对应一个哨兵配置
192.168.0.210主Redis哨兵配置文件，配置哨兵sentinel实例运行的端口36381，Redis密码，并将配置文件sentinel.conf上传至/opt/container/redis/sentinel/conf目录。 复制# 哨兵sentinel实例运行的端口 port 36381 daemonize no pidfile /var/run/redis-sentinel.pid dir /tmp sentinel monitor mymaster 192.168.0.210 26381 2 sentinel auth-pass mymaster "Redis密码" # 指定多少毫秒之后 主节点没有应答哨兵sentinel 此时 哨兵主观上认为主节点下线 默认30秒 sentinel down-after-milliseconds mymaster 30000 # 指定了在发生failover主备切换时最多可以有多少个slave同时对新的master进行同步,这个数字越小，完成failover所需的时间就越长 sentinel parallel-syncs mymaster 1 # 故障转移的超时时间 sentinel failover-timeout mymaster 180000 sentinel deny-scripts-reconfig yes1.2.3.4.5.6.7.8.9.10.11.12.13.14. 192.168.0.210从Redis哨兵配置文件，配置哨兵sentinel1实例运行的端口36382，Redis密码，并将配置文件sentinel1.conf上传至/opt/container/redis/sentinel1/conf目录. 复制# 哨兵sentinel实例运行的端口 port 36382 daemonize no pidfile /var/run/redis-sentinel1.pid dir /tmp sentinel monitor mymaster 192.168.0.210 26381 2 sentinel auth-pass mymaster "Redis密码" # 指定多少毫秒之后 主节点没有应答哨兵sentinel 此时 哨兵主观上认为主节点下线 默认30秒 sentinel down-after-milliseconds mymaster 30000 # 指定了在发生failover主备切换时最多可以有多少个slave同时对新的master进行同步,这个数字越小，完成failover所需的时间就越长 sentinel parallel-syncs mymaster 1 # 故障转移的超时时间 sentinel failover-timeout mymaster 180000 sentinel deny-scripts-reconfig yes1.2.3.4.5.6.7.8.9.10.11.12.13.14. 192.168.0.195从Redis哨兵配置文件，配置哨兵sentinel2实例运行的端口36383，Redis密码，并将配置文件sentinel2.conf上传至/opt/container/redis/sentinel2/conf目录。 复制appendonly yes port 26383 appendfilename appendonly.aof appendfsync everysec auto-aof-rewrite-min-size 10M auto-aof-rewrite-percentage 100 requirepass "设置密码" replicaof 192.168.0.210 26381 masterauth "设置密码" replica-read-only no1.2.3.4.5.6.7.8.9.10.11.
6、在两台服务器上分别执行docker-compose安装启动命令
将docker-compose-redis.yml上传至/opt/software目录，这个目录可以自己选择，然后到目录下执行安装启动命令。
复制docker-compose -f docker-compose-redis.yml up -d1. 复制[root@localhost software]# docker-compose -f docker-compose-redis.yml up -d [+] Running 10/10 ⠿ sentinel1 Pulled 15.7s ⠿ redisSlave1 Pulled 15.7s ⠿ sentinel Pulled 3.4s ⠿ a2abf6c4d29d Already exists 0.0s ⠿ c7a4e4382001 Pull complete 0.4s ⠿ 4044b9ba67c9 Pull complete 1.0s ⠿ c8388a79482f Pull complete 2.3s ⠿ 413c8bb60be2 Pull complete 2.3s ⠿ 1abfd3011519 Pull complete 2.4s ⠿ redisMaster Pulled 15.7s WARN[0015] Found orphan containers ([mysql nginx]) for this project. If you removed or renamed this service in your compose file, you can run this command with the --remove-orphans flag to clean it up. [+] Running 4/4 ⠿ Container redis-sentinel-1 Started 0.5s ⠿ Container redis-slave-1 Started 0.6s ⠿ Container redis-master Started 0.6s ⠿ Container redis-sentinel Started 0.5s1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.
通过docker ps命令可以看到redis和redis哨兵已经安装并启动成功。
复制[root@localhost software]# docker ps CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES f609322cabaa redis:latest "docker-entrypoint.s…" 59 seconds ago Up 58 seconds 6379/tcp, 0.0.0.0:26381->26381/tcp, :::26381->26381/tcp redis-master 18b75828b5b7 redis:latest "docker-entrypoint.s…" 59 seconds ago Up 58 seconds 6379/tcp, 0.0.0.0:36381->36381/tcp, :::36381->36381/tcp redis-sentinel f0f9a037c7ae redis:latest "docker-entrypoint.s…" 59 seconds ago Up 58 seconds 6379/tcp, 0.0.0.0:26382->26382/tcp, :::26382->26382/tcp redis-slave-1 e51d3b0bc696 redis:latest "docker-entrypoint.s…" 59 seconds ago Up 58 seconds 6379/tcp, 0.0.0.0:36382->36382/tcp, :::36382->36382/tcp redis-sentinel-11.2.3.4.5.6.
7、通过命令查看redis哨兵状态
进入docker容器 复制docker exec -it f609322cabaa bash1. 进入Redis目录 复制cd /usr/local/bin1. 运行info Replication命令查看主节点信息，我们可以看到connected_slaves有2个，其中slave0的ip为172.18.0.1，这是因为其获取的是docker的ip地址。 复制./redis-cli -h 127.0.0.1 -p 26381 -a "密码" info Replication # Replication role:master connected_slaves:2 slave0:ip=172.18.0.1,port=26382,state=online,offset=700123,lag=0 slave1:ip=192.168.0.195,port=26383,state=online,offset=700123,lag=0 master_failover_state:no-failover master_replid:9ee56f68d25b71158544f6cfafc677822c401ec3 master_replid2:0000000000000000000000000000000000000000 master_repl_offset:700123 second_repl_offset:-1 repl_backlog_active:1 repl_backlog_size:1048576 repl_backlog_first_byte_offset:1 repl_backlog_histlen:7001231.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16. 同样的操作方式进入到Sentinel容器，通过INFO Sentinel命令查看哨兵信息，我们可以看到有两个redis从服务，三个哨兵。 复制root@fba6d91e10f6:/usr/local/bin# ./redis-cli -h 127.0.0.1 -p 36381 INFO Sentinel # Sentinel sentinel_masters:1 sentinel_tilt:0 sentinel_running_scripts:0 sentinel_scripts_queue_length:0 sentinel_simulate_failure_flags:0 master0:name=mymaster,status=ok,address=192.168.0.210:26381,slaves=2,sentinels=31.2.3.4.5.6.7.8.
8、测试redis哨兵主备切换
手动关闭主Redis服务。 复制docker stop 5541698b65a11. 进入到Sentinel容器，通过INFO Sentinel命令查看哨兵信息，可以看到主Redis服务地址已经切换到192.168.0.195:26383。 复制root@fba6d91e10f6:/usr/local/bin# ./redis-cli -h 127.0.0.1 -p 36381 INFO Sentinel # Sentinel sentinel_masters:1 sentinel_tilt:0 sentinel_running_scripts:0 sentinel_scripts_queue_length:0 sentinel_simulate_failure_flags:0 master0:name=mymaster,status=ok,address=192.168.0.195:26383,slaves=3,sentinels=31.2.3.4.5.6.7.8. 进入到192.168.0.195的Redis容器，info Replication命令查看节点信息，我们可以看到此Redis节点已变为主服务，有一个从服务slave0:ip=192.168.0.210,port=26382。 复制./redis-cli -h 127.0.0.1 -p 26383 -a "密码" info Replication Warning: Using a password with -a or -u option on the command line interface may not be safe. # Replication role:master connected_slaves:1 slave0:ip=192.168.0.210,port=26382,state=online,offset=894509,lag=0 master_failover_state:no-failover master_replid:e9ebebdff0a5f7b7622c6c5fbfed7b1e44d84ae2 master_replid2:9ee56f68d25b71158544f6cfafc677822c401ec3 master_repl_offset:894509 second_repl_offset:884279 repl_backlog_active:1 repl_backlog_size:1048576 repl_backlog_first_byte_offset:846 repl_backlog_histlen:8936641.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.
三、配置并测试Redis集群模式（Redis Cluster）
Redis哨兵模式其实质还是主从复制，只不过加了哨兵进行自动主备切换，Redis集群模式（Redis Cluster）才是真正意义上的集群部署，它可以将数据进行分布式分片存储，但是其只能存储到db0。
1、环境准备
我们仍然使用上面的Linux服务器环境进行安装redis集群：在192.168.0.210上安装redisCluster1、redisCluster2、redisCluster3三台Reids服务；在在192.168.0.195上安装redisCluster4、redisCluster5、redisCluster6三台Reids服务。
2、准备Redis文件存放目录
准备Redis存储目录，在两台主从服务器上分别执行一下命令。
在192.168.0.210服务器上执行Redis集群所需目录及权限命令。 复制mkdir -p /opt/container/redis/cluster1/data /opt/container/redis/cluster1/conf /opt/container/redis/cluster1/logs /opt/container/redis/cluster2/data /opt/container/redis/cluster2/conf /opt/container/redis/cluster2/logs /opt/container/redis/cluster3/data /opt/container/redis/cluster3/conf /opt/container/redis/cluster3/logs chmod -R 777 /opt/container/redis/cluster1/data /opt/container/redis/cluster1/conf /opt/container/redis/cluster1/logs /opt/container/redis/cluster2/data /opt/container/redis/cluster2/conf /opt/container/redis/cluster2/logs /opt/container/redis/cluster3/data /opt/container/redis/cluster3/conf /opt/container/redis/cluster3/logs1.2.3.
在192.168.0.195服务器上执行Redis集群所需目录及权限命令。
复制mkdir -p /opt/container/redis/cluster4/data /opt/container/redis/cluster4/conf /opt/container/redis/cluster4/logs /opt/container/redis/cluster5/data /opt/container/redis/cluster5/conf /opt/container/redis/cluster5/logs /opt/container/redis/cluster6/data /opt/container/redis/cluster6/conf /opt/container/redis/cluster6/logs chmod -R 777 /opt/container/redis/cluster4/data /opt/container/redis/cluster4/conf /opt/container/redis/cluster4/logs /opt/container/redis/cluster5/data /opt/container/redis/cluster5/conf /opt/container/redis/cluster5/logs /opt/container/redis/cluster6/data /opt/container/redis/cluster6/conf /opt/container/redis/cluster6/logs1.2.3. 192.168.0.210 /192.168.0.195Redis配置文件、端口（12381、12382、12383、12384、12385、12386）、密码，并将配置文件redis.conf上传至对应目录，只需要端口不同。 复制port 12381 cluster-enabled yes #启动集群模式 cluster-config-file nodes-1.conf cluster-node-timeout 5000 cluster-announce-ip 192.168.0.210 cluster-announce-port 12381 cluster-announce-bus-port 22381 bind 0.0.0.0 protected-mode no appendonly yes #如果要设置密码需要增加如下配置： #(设置redis访问密码) requirepass 密码 #(设置集群节点间访问密码，跟上面一致) masterauth 密码1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.
3、Redis服务器docker-compose.yml文件
192.168.0.210服务器上部署两个Redis服务的docker-compose-redis-cluster.yml文件。 复制version: 3 services: ##redis节点1配置 redisCluster1: image: redis:latest restart: always network_mode: "host" container_name: redis-cluster1 command: redis-server /usr/local/etc/redis/redis.conf volumes: ##数据目录，要确保先创建好 - /opt/container/redis/cluster1/data:/data - /opt/container/redis/cluster1/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/cluster1/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" ##redis节点2配置 redisCluster2: image: redis:latest restart: always network_mode: "host" container_name: redis-cluster2 command: redis-server /usr/local/etc/redis/redis.conf volumes: ##数据目录，要确保先创建好 - /opt/container/redis/cluster2/data:/data - /opt/container/redis/cluster2/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/cluster2/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" ##redis节点3配置 redisCluster3: image: redis:latest restart: always network_mode: "host" container_name: redis-cluster3 command: redis-server /usr/local/etc/redis/redis.conf volumes: ##数据目录，要确保先创建好 - /opt/container/redis/cluster3/data:/data - /opt/container/redis/cluster3/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/cluster3/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone"1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.38.39.40.41.42.43.44. 192.168.0.195服务器上部署三个Redis服务的docker-compose-redis-cluster.yml文件。 复制version: 3 services: ##redis节点4配置 redisCluster4: image: redis:latest restart: always network_mode: "host" container_name: redis-cluster4 command: redis-server /usr/local/etc/redis/redis.conf volumes: ##数据目录，要确保先创建好 - /opt/container/redis/cluster4/data:/data - /opt/container/redis/cluster4/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/cluster4/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" ##redis节点5配置 redisCluster5: image: redis:latest restart: always network_mode: "host" container_name: redis-cluster5 command: redis-server /usr/local/etc/redis/redis.conf volumes: ##数据目录，要确保先创建好 - /opt/container/redis/cluster5/data:/data - /opt/container/redis/cluster5/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/cluster5/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone" ##redis节点6配置 redisCluster6: image: redis:latest restart: always network_mode: "host" container_name: redis-cluster6 command: redis-server /usr/local/etc/redis/redis.conf volumes: ##数据目录，要确保先创建好 - /opt/container/redis/cluster6/data:/data - /opt/container/redis/cluster6/conf/redis.conf:/usr/local/etc/redis/redis.conf - /opt/container/redis/cluster6/logs:/logs - "/etc/localtime:/etc/localtime" - "/usr/share/zoneinfo/Asia/Shanghai:/etc/timezone"1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.38.39.40.41.42.43.44.
4、在两台服务器上分别执行docker-compose安装启动命令
将
docker-compose-redis-cluster.yml上传至/opt/software目录，这个目录可以自己选择，然后到目录下执行安装启动命令。 复制docker-compose -f docker-compose-redis-cluster.yml up -d1. 复制[+] Running 3/3 ⠿ Container redis-cluster3 Started 0.5s ⠿ Container redis-cluster2 Started 0.4s ⠿ Container redis-cluster1 Started 0.5s1.2.3.4.
通过docker ps命令可以看到redis和redis哨兵已经安装并启动成功。
复制[root@localhost software]# docker ps CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES 67a48962160d redis:latest "docker-entrypoint.s…" 10 seconds ago Up 9 seconds 6379/tcp, 0.0.0.0:52381->52381/tcp, :::52381->52381/tcp redis-cluster1 b10f669691b3 redis:latest "docker-entrypoint.s…" 10 seconds ago Up 9 seconds 6379/tcp, 0.0.0.0:52383->52383/tcp, :::52383->52383/tcp redis-cluster3 d3899c9c01f6 redis:latest "docker-entrypoint.s…" 10 seconds ago Up 9 seconds 6379/tcp, 0.0.0.0:52382->52382/tcp, :::52382->52382/tcp redis-cluster21.2.3.4.5.
5、在两台服务器上分别执行docker-compose安装启动命令
登录到docker容器中。 复制docker exec -it 67a48962160d bash1. 用redis-cli创建整个redis集群。 复制cd /usr/local/bin root@localhost:/usr/local/bin# ./redis-cli --cluster create 192.168.0.210:12381 192.168.0.210:12382 192.168.0.210:12383 192.168.0.195:12384 192.168.0.195:12385 192.168.0.195:12386 --cluster-replicas 1 -a "密码" Warning: Using a password with -a or -u option on the command line interface may not be safe. >>> Performing hash slots allocation on 6 nodes... Master[0] -> Slots 0 - 5460 Master[1] -> Slots 5461 - 10922 Master[2] -> Slots 10923 - 16383 Adding replica 192.168.0.195:12386 to 192.168.0.210:12381 Adding replica 192.168.0.210:12383 to 192.168.0.195:12384 Adding replica 192.168.0.195:12385 to 192.168.0.210:12382 M: 061d7b1bf2f93df7cbf261e47a7981800d636e63 192.168.0.210:12381 slots:[0-5460] (5461 slots) master M: 6cfbf9677ab802483ddc7cbb715fe770c8de884a 192.168.0.210:12382 slots:[10923-16383] (5461 slots) master S: 5afc2e7d2da8f9d7f7ad6e99d5ad04ffbf5bdfe5 192.168.0.210:12383 replicates d54562615048044b43e368db71789829d76fa263 M: d54562615048044b43e368db71789829d76fa263 192.168.0.195:12384 slots:[5461-10922] (5462 slots) master S: 9137f05da40ce173a975fa4a5e86e65b9d3fe4e3 192.168.0.195:12385 replicates 6cfbf9677ab802483ddc7cbb715fe770c8de884a S: de04b0b6d207bd8653f2cb738cb47443c427810e 192.168.0.195:12386 replicates 061d7b1bf2f93df7cbf261e47a7981800d636e63 Can I set the above configuration? (type yes to accept): yes >>> Nodes configuration updated >>> Assign a different config epoch to each node >>> Sending CLUSTER MEET messages to join the cluster Waiting for the cluster to join >>> Performing Cluster Check (using node 192.168.0.210:12381) M: 061d7b1bf2f93df7cbf261e47a7981800d636e63 192.168.0.210:12381 slots:[0-5460] (5461 slots) master 1 additional replica(s) S: 5afc2e7d2da8f9d7f7ad6e99d5ad04ffbf5bdfe5 192.168.0.210:12383 slots: (0 slots) slave replicates d54562615048044b43e368db71789829d76fa263 S: 9137f05da40ce173a975fa4a5e86e65b9d3fe4e3 192.168.0.195:12385 slots: (0 slots) slave replicates 6cfbf9677ab802483ddc7cbb715fe770c8de884a M: d54562615048044b43e368db71789829d76fa263 192.168.0.195:12384 slots:[5461-10922] (5462 slots) master 1 additional replica(s) S: de04b0b6d207bd8653f2cb738cb47443c427810e 192.168.0.195:12386 slots: (0 slots) slave replicates 061d7b1bf2f93df7cbf261e47a7981800d636e63 M: 6cfbf9677ab802483ddc7cbb715fe770c8de884a 192.168.0.210:12382 slots:[10923-16383] (5461 slots) master 1 additional replica(s) [OK] All nodes agree about slots configuration. >>> Check for open slots... >>> Check slots coverage... [OK] All 16384 slots covered.1.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.38.39.40.41.42.43.44.45.46.47.48.49.50.51.52. 登录redis，并查看集群信息。 复制# 查看集群信息 cluster info # 查看节点列表 cluster nodes1.2.3.4. 复制[root@localhost software]# docker exec -it 407e3847371a bash root@localhost:/data# cd /usr/local/bin root@localhost:/usr/local/bin# redis-cli -c -h 127.0.0.1 -p 12383 -a "密码" 127.0.0.1:12383> cluster info cluster_state:ok cluster_slots_assigned:16384 cluster_slots_ok:16384 cluster_slots_pfail:0 cluster_slots_fail:0 cluster_known_nodes:6 cluster_size:3 cluster_current_epoch:6 cluster_my_epoch:4 cluster_stats_messages_ping_sent:173 cluster_stats_messages_pong_sent:163 cluster_stats_messages_meet_sent:1 cluster_stats_messages_sent:337 cluster_stats_messages_ping_received:163 cluster_stats_messages_pong_received:174 cluster_stats_messages_received:337 127.0.0.1:12383> cluster nodes 061d7b1bf2f93df7cbf261e47a7981800d636e63 192.168.0.210:12381@22381 master - 0 1696952366541 1 connected 0-5460 de04b0b6d207bd8653f2cb738cb47443c427810e 192.168.0.195:12386@22386 slave 061d7b1bf2f93df7cbf261e47a7981800d636e63 0 1696952366541 1 connected 5afc2e7d2da8f9d7f7ad6e99d5ad04ffbf5bdfe5 192.168.0.210:12383@22383 slave d54562615048044b43e368db71789829d76fa263 0 1696952366039 4 connected 9137f05da40ce173a975fa4a5e86e65b9d3fe4e3 192.168.0.195:12385@22385 slave 6cfbf9677ab802483ddc7cbb715fe770c8de884a 0 1696952367043 2 connected 6cfbf9677ab802483ddc7cbb715fe770c8de884a 192.168.0.210:12382@22382 master - 0 1696952365537 2 connected 10923-16383 d54562615048044b43e368db71789829d76fa263 192.168.0.195:12383@22384 myself,master - 0 1696952366000 4 connected 5461-109221.2.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.
搭建Redis集群模式一定要注意，docker-compose配置一定要将network_mode设置为"host"模式，且不需要端口映射。如果创建集群时，一直显示等待连接，那么需要配置防火墙，放开Redis集群端口。
